£360.00

With 4inch Spindle Plate as standard with 4inch (100mm) 3-jaw self-centering Chuck. Utilising full use of the 20mm Spindle bore which is restricted on a 3" chuck machine.

***** 350mm Between Centres.***** 550W Motor ****Digital Readout of the spindle speed AND tailstock lever lock****

Brand new stock. Ideal for the professional engineer or model maker alike - this is a superb lathe at a bargain price!

With this lathe you will get a superb workhorse, a guarantee, and a full after sales service.

Specifications:
Power 550W
Distance between centres : 350mm
Swing Over Bed: 180mm
Swing Over Cross Slide: 110mm
Taper: MT3
Tailstock Taper: MT2
Spindle Speed: 50 - 2500rpm
Spindle Bore: 20mm
Cross slide Travel: 65mm
Chuck diameter 100mm (Integral spindle plate is 100mm no adapter plate required)
Range of Metric Threads: 0.5 - 2.5mm.
Range of Imperial Threads: 12 - 52 TPI.
Spindle Accuracy: 0.01mm.
Size with packaging is L: 81cm W: 32cm H: 31cm
Operating instructions enclosed.
American circuit board
230v 50Hz motor
Actual dimensions of lathe - 29in.x 10in.x 9½ in.
Net weight/Gross weight : 45/48Kg

The following postcodes would be charged extra: IV, KW1-14, PA34, PA37-39, PH19-40, PH41 Sector 4 & PH49-50. Please contact us for further information.

*Please note that the images and specifications stated are for reference use only. Actual products may vary.
find out more

£1,230.00

FEATURES:
Most useful, heavy duty homeshop lathe.
V-way bed is hardened and precision ground.
Super width bedway gives greater capacity.
Spindle is supported by precision tapered roller bearing.
Automatic feed and threading are fully interlocked.
T-slotted cross slide.
Adjustable gibs for slideways.
Top design of gearbox for improved function.
Cuts right and left hand threads.
Tailstock may be offset for turning tapers.
A reversing switch is included for added versatility.
Equipped with high quality belt and control board.
Tolerance test certificate, test flow chart included.
With powered cross feed

SPECIFICATION:
Model No.
Distance between centers 700mm
Swing over bed 280mm
Swing over cross slide 165mm
Taper of spindle bore MT4
Spindle bore 26mm
Number of spindle speeds Variable
Range of spindle speeds 50~2000rpm
Range of cross feeds 0.02~0.28mm/r
Range of longitudinal feeds 0.07-0.20mm/r
Range of inch threads 8-56T.P.I
Range of metric threads 0.2-3.5mm
Top Slide travel 50mm
Cross slide travel 140mm
Tailstock quill travel 80mm
Taper of tailstock quill MT2
Motor 0.75/1.1KW
Packing size 1400 x 700 x 680mm
Net weight 210kgs

STANDARD ACCESSORIES:
Splash guard 1pc
Chip tray 1pc
Toolbox&tools 1set
Speed counter

OPTIONAL ACCESSORIES:
Four-jaw chuck 1set
Backplate 1pc
Follow rest 1pc
Steady rest 1pc
Face plate 1pc
ER25 Collet chuck 1set
Collet holder 1set
Turning tools 1set
Quick change tool post 1set
Stand

The following postcodes would be charged extra: IV, KW1-14, PA34, PA37-39, PH19-40, PH41 Sector 4 & PH49-50. Please contact us for further information.

*Please note that the images and specifications stated are for reference use only. Actual products may vary.
find out more

£16.00

2 x 350mm adjustable coolant hoses
Brass taps
Switchable magnetic base with 110lb pull
Brass inlet connector
find out more

£79.00

Perfect for setting work at any angle for milling, grinding or drilling
Heavy, rugged, graded casting
Machined 1/2" 'T' slots
Graduated 90 degrees for setting 45 degree either side of vertical
Accuracy of table surface - 0.0005"
find out more

£70.00

This item is an excellent tilt and swivel vice. It is well made with jaws closing nicely in parallel - ideal for milling or drilling and at a bargain price!

Jaw width - 75mm
Opening - 75mm
Overall height - 120mm
Overall width - 140mm
Bolt slot centres - 180mm
Net weight - 9.17Kg
Gross weight - 9.72Kg
Swivel - 360°
Tilt - 90°
find out more
