AMA714B Brushless mini lathe with Metal gears + 2 axis DRO

AMA714B Brushless mini lathe with Metal gears + 2 axis DRO

Price: £992.00 (Including VAT at 20%)

Click for larger image

 Ask a question
 Email a friend
Additional items you may need

Product Description

The Amadeal Mini Lathe - 7x14 Machine with DRO & 4" Chuck NOW WITH BRUSHLESS MOTOR + METAL GEARS + 2 AXIS DRO - Top Spec - Lowest Price


N.B. 100mm (4") CHUCK FITTED AS STANDARD - 100mm SPINDLE PLATE - NO ADAPTER PLATE NEEDED.

This machine is by far-and-away the best spec mini-lathe for the money - fully guaranteed and every single spare part stocked.

****** A GENUINE BARGAIN PRICE ***** With 4inch Spindle Plate as standard with 4inch (100mm) 3-jaw self-centering Chuck*****

***** 350mm Between Centres ***** 500W Motor ***** Digital Readout of the spindle speed ***** Tailstock lever lock *****

Brand new stock from manufacturer - Ideal for the professional engineer or model maker alike - This is a superb lathe at a bargain price!

We have a range of accessories to go with this lathe at discount prices.

A FULL YEARS WARRANTYand a full after sales service.

***** Can be viewed and collected from my east London premises *****


The main specifications are:

Power 500W
Distance between centres : 350mm
Swing Over Bed: 180mm
Swing Over Cross Slide: 110mm
Taper: MT3
Tailstock Taper: MT2
Chuck diameter: 100mm
Spindle Speed: 50 - 2500rpm
Spindle Bore: 20mm
Cross slide Travel: 65mm
Chuck diameter 100mm (Integral spindle plate is 100mm and can take 3 or 4 jaw chucks - no adapter plate required)
Range of Metric Threads: 0.5 - 2.5mm.
Range of Imperial Threads: 12 - 52 TPI.
Spindle Accuracy: 0.01mm.
Packing size: 750x380x380mm
Operating instructions enclosed.
American circuit board
180v DC motor

Net weight/Gross weight : 42/50Kg.

Includes set of external jaws, tray, rear splash guard, set of hex keys, spanner, oil can.
Several other accessories available
240V (plugs into UK domestic ring main)
N.B. The above spec. should be treated as a guide as there can sometimes be a small variance from the quoted details.

Carriage is free to most of UK mainland (but excludes Northern Ireland, Islands & several Scottish postcode areas). Next working day when ordered before 1pm! A £40 surcharge with our economy courier service is applicable to customers in Northern Ireland, Scottish Highlands and Islands.

Contact me beforehand for a quotation. Please provide a phone number with your account for the couriers.
